Ductile Iron Gate Valve Rising Stem
- Weights:
- Sizes:
- Class:
- Pressure:
- Temperatures:
- 15kg - 870kg
- DN 50 – 600
- 150
- PN16
- -5°C to 400C

Application
The Ductile Iron Gate Valve Rising Stem has the bottom end of the stem attached to the Disc. When the handwheel is turned in a clockwise rotation, the stem rises through the handwheel utilizing the yolk, drawing the stem out of the valve, and the disc (gate) out of the way of the media. Because the stem rises above the handwheel, it is easy to identify from a distance whether the valve is open or closed, so it is well suited to large, open environments.
The stem and its thread are protected from corrosive mediums by the bonnet and there is no added resistance from the medium in operating the handwheel as the stem and mediums do not occupy the same space. One of the key advantages of a rising stem gate valve is its ability to provide a reliable and tight shut-off. When fully closed, the gate or wedge comes into contact with the valve seats, creating a tight seal that prevents any fluid from flowing through. This feature makes it ideal for applications where a complete closure is required, such as pipelines, refineries, power plants, and water treatment facilities.
Recommended: For Pricing, Availability, Advantages, Disadvantages, and Common Industry Uses, see Valvetech Gate Valves
Diagram

# | Part | Material |
---|---|---|
1 | Handwheel | Ductile Iron A536 |
2 | Yoke Sleeve | SS304 |
3 | Gland Bolt | Carbon Steel |
4 | Gland Bolt Nut | Carbon Steel |
5 | Gland | Ductile Iron A536 |
6 | Buffing Box | SS304 |
7 | Gland Packing | Flexible Graphite |
8 | Bonnet Bolt | Carbon Steel |
9 | Bonnet Bolt Nut | Carbon Steel |
10 | Bonnet | Ductile Iron A536 |
11 | Bonnet Gasket | Graphite & SUS304 |
12 | Stem | SS410 |
13 | Body | Ductile Iron A536 |
14 | Disc Seat Ring | SS304 |
15 | Disc | Ductile Iron A536 |
16 | Body Seat Ring | SS304 |
Dimensions
All measurements listed are expressed in millimetres, unless otherwise noted. Product weight is represented in kilograms. DN size is provided in millimetres and NPS size is given in inches. These values correspond to the diagram label and its associated part.
NPS | DN | L | øD | øD1 | C | H | W | Kg |
---|---|---|---|---|---|---|---|---|
2 | 50 | 178 | 152 | 120 | 15.90 | 330 | 180 | 15 |
2.5 | 65 | 190 | 178 | 139 | 17.50 | 350 | 180 | 17 |
3 | 80 | 203 | 191 | 152 | 19.10 | 428 | 200 | 23 |
4 | 100 | 229 | 229 | 190 | 23.90 | 513 | 200 | 33 |
5 | 125 | 254 | 254 | 216 | 23.90 | 625 | 250 | 42 |
6 | 150 | 267 | 279 | 241 | 25.40 | 703 | 250 | 48 |
8 | 200 | 292 | 343 | 298 | 28.60 | 952 | 280 | 85 |
10 | 250 | 330 | 406 | 362 | 30.20 | 1,150 | 350 | 125 |
12 | 300 | 356 | 483 | 432 | 31.80 | 1,314 | 350 | 175 |
14 | 350 | 381 | 533 | 476 | 35.00 | 1,622 | 450 | 250 |
16 | 400 | 406 | 597 | 540 | 36.60 | 1,755 | 450 | 315 |
18 | 450 | 432 | 635 | 578 | 39.70 | 1,993 | 600 | 578 |
20 | 500 | 457 | 699 | 635 | 42.90 | 2,200 | 600 | 715 |
24 | 600 | 508 | 813 | 749 | 47.70 | 2,640 | 600 | 870 |
P/T Ratings
Valvetech’s Pressure/Temperature Ratings according to ANSI B16.10
Temperature ° Celsius | -10°C to +38°C | 93°C | 149°C | 204°C | 260°C | 316°C | 372°C | 400°C |
Pressure Bar | 19.6 | 17.9 | 15.9 | 13.8 | 11.7 | 9.7 | 7.6 | 6.5 |
Other Products
Ductile Iron Gate Valve
Non-Rising Stem VT68N
Weight: 14kg – 780kg
Sizes: DN 50 – 600
Class: 150
Pressure: PN16
Temperatures: -10°C to 400°C
Cast Iron Gate Valve
Rising Stem Valve VT86
Weight: 16kg – 1,341kg
Sizes: DN 50 – 600
Class: 125
Pressure: PN14
Temperatures: -10°C to 230°C
Specifications
Models
VT84N
Body Material
Iron Grade
Stem Operation
Rising
Trim
SS304
Drill Tables
Table 10, 16, D, ASA150
Standards
Design Standard MSS SP-70
Flanges conform to ANSI B16.5
Face to Face conform to ANSI B16.10
Services
Water, Oil, Gas, Steam
Industries
Petrochemicals and Petroleum, Refineries, Primary Energy, Agriculture, Water Works, HVAC
Priority Media
Acetylene, Borax, Butane Gas, Carbon Dioxide, Castor Oil, Caustic Soda, Detergents, Diesel Fuels, Hydraulic Oil, Linseed Oil, Nitrogen, Propane Gas, Steam, Tributyl Phosphate
Inventory Code and Description
DIGATEVT84N
DI GATE RS 304SS TRIM CL150 FLANGED
Ductile Iron Rising Stem 304 Stainless
Steel Trim Class 150 Flanged
Also Known As
Outside Screw and Yoke (OS+Y) Gate
Valve
Rotational Stem Design Gate Valve
Rising Stem Wedge Gate Valve
Sluice Valve
