Brass Gate Valve Non-Rising Stem
- Weights:
- Sizes:
- Class:
- Pressure:
- Temperatures:
- 250g - 6kg
- DN 15 – 100
- 125
- PN14
- -2°C to 120°C
Application
The Brass Gate Valve Non-Rising Stem is known for its reliability, longevity, and ease of operation, and is used in plumbing and industrial applications to control and isolate the flow of fluids. The cast iron handwheel offers positive shutoff, and the screw-in bonnet ensures a durable, pressure-tight seal due to the BSP screwed ends. The female/female ends also allows for ease of installation in irrigation pipelines.
Due to the durable and corrosion-resistant brass, a solid wedge, integral seats and bi-directional services, the gate valve makes for a perfect choice for water, oils and gas services. Unlike a rising stem valve, the non-rising stem remains stationary while the gate inside the valve moves vertically to control the flow, so it doesn’t require additional vertical clearance for stem movement. This reduces the risk of damage or interference in compact spaces or areas with limited accessibility.
Recommended: For Pricing, Availability, Advantages, Disadvantages, and Common Industry Uses, see Valvetech Gate Valves
Diagram
# | Part | Material |
---|---|---|
1 | Nut | SS304 |
2 | Nameplate | Aluminium |
3 | Handwheel | Cast Iron |
4 | Stem | Brass Hpb57-3 |
5 | Lock Nut | Brass Hpb57-3 |
6 | Packing | PTFE |
7 | Locking Cap | Brass Hpb57-3 |
8 | Bonnet | Brass Hpb57-3 |
9 | Seal Ring | PTFE |
10 | Wedge | Brass Hpb57-3 |
11 | Body | Brass Hpb57-3 |
Dimensions
All measurements listed are expressed in millimetres, unless otherwise noted. Product weight is represented in kilograms. DN size is provided in millimetres and NPS size is given in inches. These values correspond to the diagram label and its associated part.
NPS | DN | A | B | C | H | L | Grams |
---|---|---|---|---|---|---|---|
½ | 15 | 55 | 12 | 14 | 70 | 41 | 245 |
¾ | 20 | 55 | 13 | 15 | 72 | 43 | 290 |
1 | 25 | 60 | 14 | 19 | 83 | 48 | 410 |
1¼ | 32 | 70 | 14 | 27 | 105 | 59 | 710 |
1½ | 40 | 70 | 15 | 35 | 115 | 60 | 860 |
2 | 50 | 80 | 18 | 45 | 130 | 67 | 1,300 |
2½ | 65 | 100 | 22 | 60 | 185 | 81 | 2,600 |
3 | 80 | 110 | 25 | 75 | 200 | 98 | 3,920 |
4 | 100 | 140 | 26 | 90 | 245 | 102 | 6,100 |
Other Products
Brass Ball Reduced Bore Valve Nickel Plated Screwed BSP 102N
Weight: 120g – 6.25kg
Sizes: DN 8 – 100
Pressure: PN20
Temperatures: -2°C to 120°C
Brass Ball Full Bore Valve Nickel Plated Screwed BSP 105N
Weight: 110g – 8.5kg
Sizes: DN 8 – 100
Pressure: PN40
Temperatures: -2°C to 120°C
Specifications
Models
201
Body Material
Stem Operation
Non-Rising
Standards
BSP-G Screwed
Threading
Female / Female
Services
Water, Oil, Gas, Steam
Industries
Agriculture, Irrigation, Water Oil, Gas Services
Priority Media
Butane Gas, Butyl Acetate, Wet Carbon Dioxide, Carbon Monoxide, Caustic Soda, Diesel Fuel, Ethanol, Hydrogen Gas, Freon Gas, Leaded and Unleaded Gasoline, Lubricants, Oxygen, Paraffin, Potable Water, Propane Gas
Inventory Code and Description
BRGATEN201
BRASS GATE VALVE SCR BSP
Brass Gate Valve Cast Iron Handwheel
Screw Gate British Standard
BRGATEA201
BRASS GATE VALVE SCR BSP
Brass Gate Valve Aluminium Alloy
Handwheel Screw Gate British Standard
Also Known As
Sluice Valve
Shut-off Valves
Water Gate Valves
Download
Please click the following PDF icon to download this specification sheet
Product Brochure
1MB, PDF
